The AMSOIL FFK-60 Fuel Filter incorporates both a primary and secondary filter for maximum fuel cleanliness. The primary 10 micron filter, located in the Horizontal Fuel Conditioning Module (HFCM), performs initial fuel cleansing before sending the clean pressurized fuel to secondary four micron filter, mounted to the oil filter housing.

The secondary fuel filter includes a fuel pressure regulator and an orifice on top of the housing that bleeds air out of the housing and back to the fuel tank. Following its trip through the secondary filter, fuel is returned to the HFCM, where it is either directed to the tank or returned to the primary filter.

AMSOIL INC. of Superior, WI has introduced a new premium, high efficiency cartridge oil filter utilizing nanofiber technology for Ford 6.0L diesel engines ranging from 2003 to 2006. The new EaO-88 is the world's first oil filter cartridge for diesel applications using advanced submicron full synthetic media. The EaO-88 provides an efficiency of 98.7% at 16 microns, significantly higher than the OEM filter.

The rigid construction of this filter is due to a polymeric center tube and end caps, along with its proprietary composition incorporating special grade nanofiber synthetic media, enabling the filter to last up to 1 year or 25,000 miles when used in conjunction with AMSOIL synthetic motor oil. Because of its improved oil flow, an additional benefit of this synthetic filter media is that oil is delivered to key engine components quicker, thus enhancing the lubrication process during cold weather starts.

• Superior filtration efficiency
• Excellent flow characteristics
• Reduced engine wear
• Rugged and durable design


Fast Fact:  A nanofiber is less than one micron in diameter.  A human hair is 80 microns.
